Incoloy Alloy
Created with Pixso. Sheet Plate Inconel 601 Heat Treatment Equipment Incoloy Alloy 800H 600 MPa

Sheet Plate Inconel 601 Heat Treatment Equipment Incoloy Alloy 800H 600 MPa

Brand Name: Runlai
Model Number: Incoloy 800H
MOQ: 10 Kg
Price: Negotiable
Delivery Time: 20~40 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
ISO9001 ROHS
Product Name:
Incoloy 800H Tube
Material:
Ni Fe Cr
Ni (Min):
30%
Density:
7.94 G/cm3
Melting Point:
1350-1400 ℃
Elongation (≥ %):
30%
Yield Strength:
260 MPa
Tensile Strength:
600 MPa
Standard:
ASTM, ASME
Application:
Manufacture Of Furnace Linings, Heating Elements, Etc. In Heat Treatment Equipment
Packaging Details:
Packed in Spool Carton box, Coil package with polybag,then in woodencase
Supply Ability:
300 tons per month
Highlight:

Heat Treatment Equipment Sheet Plate

,

Inconel 601 Sheet Plate

,

Incoloy Alloy 800H Sheet Plate

Product Description

Sheet Plate Inconel 601 Heat Treatment Equipment Incoloy Alloy 800H 600 MPa





The hot-rolled steel plate products produced have excellent properties such as high strength, good toughness, easy processing, and good weldability, so they are widely used in manufacturing industries such as ships, automobiles, bridges, buildings, machinery, and pressure vessels.



Parameter


Chemical composition:
Iron (Fe): 39.5% (minimum content)
Nickel (Ni): 30.0% (minimum content)
Chromium (Cr): 19.0-23.0% (minimum and maximum content)
Copper (Cu): ≤0.75% (maximum content)
Aluminum (Al): ≤0.15-0.60% (maximum and minimum content)
Carbon (C): ≤0.10% (maximum content)
Titanium (Ti): ≤0.60-1.20% (maximum and minimum content)
Density: 7.94 g/cm3
Melting point: about 1350-1400 degrees Celsius
Tensile strength: ≥600 MPa (MPa)
Yield strength: ≥260 MPa (MPa)
Elongation: ≥30%



Incoloy Ni Cr Fe C Mn S Si Cu Al Ti
800H 30.0-35.0 19.0-23.0 39.5min 0.10max. 1.50max. 0.015max. 1.0max. 0.75max. 0.15-0.60 0.15-0.60



AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
AMS 5766 Bar Incoloy 800H Nickel N08810 - Bar
AMS 5766 Custom Tube Incoloy 800H Nickel N08810 - Custom Tube
AMS 5871 Plate Incoloy 800H Nickel N08810 - Plate
AMS 5871 Sheet Incoloy 800H Nickel N08810 - Sheet
AMS 5871 Strip Incoloy 800H Nickel N08810 - Strip



Comparison with other alloys


Incoloy 800: For applications that require high temperature strength but are not in extreme conditions, commonly found in heat exchangers, furnace components and chemical equipment.
Incoloy 800H: For applications that require higher strength at high temperatures, common in ethylene cracking furnaces, hydrocarbon cracking and heat treatment equipment.
Incoloy 800HT: For demanding high temperature applications, common in power generation, steam superheaters and high temperature heat exchangers.



Specific Applications


  1. Furnace plates, fixtures and radiant tubes: Incoloy 800H tubes are used to manufacture furnace plates, fixtures and radiant tubes, and are able to resist carbonization and handle thermal cycling.
  2. Annealing equipment: In annealing equipment, Incoloy 800H tubes are able to withstand high temperatures for long periods of time in a controlled atmosphere.



Advantages and Characteristics


  • Corrosion resistance: Incoloy 800H alloy performs well in a variety of corrosive media, including hydrochloric acid, sulfuric acid, acetic acid, phosphoric acid, etc. It has excellent resistance to stress corrosion cracking in chlorides, low concentration NaOH aqueous solutions and high temperature and high pressure water. The nickel content is sufficient to prevent chloride ion stress corrosion cracking, and nickel, together with molybdenum and copper, also has excellent resistance to reducing chemicals.
  • The chromium content provides resistance to oxidizing environments.
  • High temperature stability: Incoloy 800H alloy has excellent stability at high temperatures and can be used for a long time at temperatures up to 800°C without significant degradation.
  • Through reasonable heat treatment process, its microstructure can be adjusted, the mechanical properties can be optimized, and good processing and forming capabilities can be maintained.
  • Good machinability: Incoloy 800H pipes can be processed and formed by a variety of traditional methods, such as casting, forging, rolling and welding.
  • Excellent weldability: Incoloy 800H alloy has good adaptability to various welding methods, such as argon arc welding, electron beam welding, etc. The welded joint has high strength and low crack sensitivity.



Sheet Plate Inconel 601 Heat Treatment Equipment Incoloy Alloy 800H 600 MPa 0Sheet Plate Inconel 601 Heat Treatment Equipment Incoloy Alloy 800H 600 MPa 1
